Current Status Currently Testing Updated August 2026
Testing Progress 25% Complete

Lab Tested. Outlaw Approved.

Mayku Multiplier

Large format pressure forming for aligners, retainers, night guards, and bleaching trays. Run full 428mm bed or the 7 shot plate for your existing stock.
Overall score Still Testing
Rating Not Yet Rated
Time tested 1.5 Months

A long term review based on real production inside our own orthodontic lab.

Reviewed by Orthodontic Lab Pros
Reviewed by Orthodontic Lab Pros Reviewed Started July 2026 • Updated August 2026
✓ Independent review ✓ Tested in real production ✓ Long term ownership experience

AT A GLANCE

Product Specifications

The important details, requirements and capabilities in one place.

Technical Specifications

Mayku Multiplier Specifications

Mayku
Version: Mayku Dental
Connectivity: WiFi
Power Requirements: 110-240V, 12A/6A (Single Phase) Max power: 1500W
Footprint: 23"(L) x 20"(W) x 16.5"(H) Weight 125lbs
Key Features: Large 380mm safe forming area, built in air compressor, up to 60 psi (4 Bar) of forming pressure
Material Type: Up to 7 appliances per cycle with 7 shot reducing plate to use any of your current materials 120mm to 125.mm or up to 20 appliances per cycle with 428mm blanks.
Cycle Times: Retainers/Aligners/Whitening trays, Using only PETG: ~5mins. Up to 7 appliances per cycle with 7 shot reducing plate. Up to 20 appliances per cycle with 428mm blanks
Cycle Times: Mouth Guards/Night Guards, Using only EVA: ~7 mins. Up to 7 appliances per cycle with 7 shot reducing plate. Up to 20 appliances per cycle with 428mm blanks
Installation: 1 Hour
Training Time: 3 to 4 Hours

Mayku Output

Supported Appliances

Clear retainers (Essix style retainers)
Clear aligners
Bleaching trays
Night guards
Sports guards
Material Thickness: 0.5 mm to 5.0 mm, depending on the appliance and thermoforming material used.
Vacuum formed surgical guides and thermoformed dental templates (using compatible materials)
Thermoformed lab trays and custom appliances made from compatible thermoformable plastics using Custom Mode

INSIDE THE SETUP

From Delivery to Production

Follow the real installation process, setup requirements, training and the first successful production result.

How It Arrives

The exciting part is finally here. Your new machine has arrived. With a little help you can remove the shipping box from the pallet and get it into your lab.

Through the Door and Into the Lab

The delivery pallet may be too large for a standard doorway. Once the shipping box is removed from the pallet it should easily fit through most standard doorways.

Final Setup Before Testing

At approximately 125 pounds, the Mayku is not a one person lift. Have two people ready to safely position the machine and ensure your bench or countertop is sturdy enough to support its weight.

Inside the Mayku Shipping Crate

The Mayku machine arrived with the boxes and accessories shown here.

Note: Dental models are shown for demonstration purposes only.

Initial Setup

Our first setup before production. A simple workspace focused on getting familiar with the machine and dialing everything in. Let the testing begin.

Getting to Know the Controls

After connecting to Wi Fi we spent some time getting familiar with the interface and controls while learning how to create custom material profiles for the materials we use every day in our lab.

Ready for the First Batch

We were excited to make our first pull using the large 428mm PETG material.

Note: For the initial test run, we decided to start with only 10 models.

The Moment of Truth

We were very happy with our first results. Since the 428mm PETG material profile is already built into the Mayku, we were able to focus on learning the machine before moving on to custom material profiles.

Our First 7 Shot Test

Next we tested some 2 mm Keystone material with the 7 shot setup. Considering it was our first attempt at creating a custom profile, it came out decent.

THE 7 STEP PROVE IT PROCESS

Talk Is Cheap.
Every Product Has to PROVE IT.

All products tested must prove itself through the same 7 step real world evaluation process.
Only then can it earn an official Ortho Outlaw rating.

Purchase Research

Identify a production problem, review the manufacturer's claims and decide if the product is worth a shot in an ortho lab.

Receive and Install

Document unboxing, installation, setup requirements, learning curve and everything needed to get up and running.

Operate in Production

Put the product to work on real cases inside an active orthodontic lab to evaluate everyday performance, reliability and workflow impact.

Verify Performance

Study production, reliability, maintenance, customer support, ROI value and overall consistency during everyday lab production.

Evaluate Results

Calculate performance, workflow impact, limitations and available alternatives against the manufacturer's claims and real world expectations.

Invest or Ignore

Decide whether the product has proven itself, earns a place in an ortho lab or practice and if it's worth the investment.

The Verdict

Tally the scorecard, explain the trade offs and deliver the final recommendation.

THE STANDARD

Approval Isn't Given. It's Earned.

Is there a product or piece of equipment the orthodontic community has been talking about? Let us know. We may feature it in an upcoming review.

Have a product or equipment you want us to test? Prove It!

CALL865-418-6898 EMAILSend Us Your Idea

How We Work With Manufacturers

Industry Relationships Never Determine the Outcome.

Some of the products and equipment featured in our reviews are purchased by us for our own ortho lab. Others are provided or sponsored by manufacturers to support the review process through product access, technical information or other collaborative efforts. Those relationships never determine the outcome. Every product is evaluated using the same PROVEN IT review process and every rating is earned through real ortho lab testing, long term performance and one simple question: Would I confidently use it in my own lab?

Some companies become resale partners. Others simply earn our respect.
01 How much does it cost?

At the time of our review the Mayku Multiplier Dental Bundle is priced at $11,999.

The Dental Bundle includes everything needed to begin forming appliances right out of the box, including:

  • Mayku Multiplier pressure forming machine
  • 7 Shot Reducing Plate
  • Dental Firmware with preloaded material profiles
  • Ability to create unlimited custom material profiles
  • Starter Kit
  • Trial PETG and EVA material sheets
  • Built in air compressor
  • Wi Fi firmware updates
  • 12 month warranty
Important: We'll continue updating this review with any additional accessories or upgrades we feel are worth purchasing as we spend more time with the machine.
02 Does the Mayku come ready to use out of the box?

Yes. The machine arrives mostly assembled and only requires a few setup steps before you can begin. After connecting to Wi Fi and completing the initial registration we were ready to start learning the machine and making our first pulls.

Bottom line: Easy setup. We were up and running in about an hour with very little assembly required.
03 Can you use your own thermoforming materials?

Yes. One of the biggest advantages of the Mayku is the ability to create custom material profiles. We successfully created our first custom profile for Keystone material and plan to continue testing many other orthodontic materials throughout this review.

Bottom line: The ability to create custom material profiles could be one of the Mayku's smartest moves.
04 Does it require an external air compressor?

No. The Mayku has a built in compressor so it only requires a standard electrical outlet. There is no need for shop air or additional plumbing which makes installation quick and simple. As an added bonus the machine includes an air outlet on the back that can be used for accessories such as a blow gun.

Bottom Line: No external compressor means a cleaner and simpler installation.
05 Is the interface easy to learn?

We found the interface to be clean and straightforward. After connecting to Wi Fi we spent some time learning the controls and creating our first custom material profiles.

Bottom line: The controls are easy to learn. Developing custom material profiles takes more time but becomes easier as you gain experience with different materials.
06 Is the 7 Shot Plate included?

Yes. The Dental Bundle includes the 7 Shot Plate which allows smaller production runs using standard size material instead of the full 428 mm sheet. We will be testing both configurations.

07 How much bench space does it require?

Footprint: 23"(L) x 20"(W) x 16.5"(H) Weight 125lbs

The Mayku is larger than a traditional pressure former, so plan your workspace before delivery. The machine weighs approximately 125 pounds so two people are recommended for lifting it into place. Make sure your countertop is sturdy enough to safely support the machine and leaves enough room to load material and remove finished pulls.

08 How much maintenance is required?

Most routine maintenance involves keeping the machine clean and following the on screen maintenance reminders. Regular tasks include wiping the seal and forming bed clean checking the heat sensor and reflector for debris occasionally lubricating the guide rails if needed and draining the internal air tanks to remove any moisture buildup. The machine also includes built in maintenance prompts that guide you through these tasks when they are due.

As we continue long term testing we will also report how the machine holds up over thousands of forming cycles and whether any components require replacement over time.

Bottom line: So far maintenance has been minimal and easy to perform. We will continue updating this review as we put more hours on the machine.
09 Can I finance the machine?

Financing may be available for qualified buyers. Low or no money down options may be available through Orthodontic Lab Solutions, depending on approval and current lending programs.

View financing information
10 Where is it manufactured?

Designed by Mayku in the United Kingdom and shipped from a US distribution center.

Our review unit shipped from the Memphis, Tennessee distribution center, although shipping locations may vary depending on your region.

These answers reflect our experience with the Mayku in our own laboratory. Results will vary based on appliance mix, production volume, staffing and workflow.
